Band Crochet Machine



DH 608

  DH 608-3B is a model for the production of elastic or inelastic tape in the range of lady’s underwear, rigid and elastic body-belt, medical bandages…etc.
1. Double swing device decreases needle being broken.
2. Optional long weft shifting suitable for medical bandage and body-belt.


Specification


MODEL DH 608-3B
Net weight of machine 700 kgs
Net weight of creel 260 kgs
Weight of creel and crate 300 kgs
Weight of machine and crate 800 kgs
Crate of machine 170*127*180 cm
Crate of creel 285*74*33 cm



Optional device
Inverter 1 set
Creel for 260 bobbins 2 sets
Warping yarn feeding roller 1 set
Creel rubber feeding device 1 set
Long weft shifting device(12") 1 set



Technical data
Operation width 600 mm
Gauge 15,18,20 gg
Weft bar 3 bars



Standard equipment & Accesorie
Operation motor (1.5HP) 1 set
Weft yarn bar 2 sets
Warp yarn bar 1 set
Elastic bar 1 set
Warp yarn automatic tension device 1 set
Automatic stop motion device 1 set
Elastic yarn feeding roller 2 sets
Finished product collecting roller 2 sets
Tool 1 set
Weft tube 200 pcs
Lead block 10 pcs
Beard needle 200 pcs
Dropper 600 pcs



Velcro Crochet Machine



 DH 600



DH 600-SN is a feature of COMPOUND NEEDLE crochet machine.
Most characteristic is in the production of elastic Female Velcro, Lace with lock stitch…




Specification


MODEL DH 600-SN
Net weight of machine 700 kgs
Net weight of creel 130 kgs
Weight of creel and crate 180 kgs
Weight of machine and crate 800 kgs
Crate of machine 206*127*190 cm
Crate of creel 285*74*26 cm



Optional device
Creel for 260 bobbins 1 set
Long weft shifting device(10") 1 set



Technical data
Operation Width 500 mm
Gauge/Inch 15,20 gauge/inch
Weft bar 2 bars
Cam for terry device(1:1 or 2:1) 1 set
Chain link ratio 12 ~ 48 pcs
Speed 1000 rpm



Standard equipment & Accesories
Operation motor 1 set
Weft yarn bar 2 sets
Elastic bar 1 set
Terry fasten bar 1 set
Terry transmission bar 1 set
Warp yarn feeding roller 1 set
Weft yarn feeding roller 1 set
Elastic yarn feeding roller 2 sets
Automatic stop motion device 1 set
Finished product collector 1 set
Automatic lubricator 1 set
Tool 1 set
Chain gear (06B) 1 set
Inverter 1 set
Lead block 10 pcs
Terry lead block 5 pcs
Terry tube (K0034-1) 300 pcs
Weft tube (2.0) 200 pcs
Compound needle 300 sets
Warp needle 400 pcs
Dropper 600 pcs
